When Stability Matters

RHK manufactures high-performance leveling cylinders—also known as stabilizers, landing gear, or outriggers—designed to provide safe, stable working platforms. Used across transport, hauling, oil and gas and many other industrial applications, our cylinders are custom engineered and built in our Edmonton facility to deliver reliable performance, fast lead times, and proven industry expertise.

Designed and Manufactured to Your Requirements

Custom Bore Size

Stroke Length

Lifting Capacity

Mechanical/Hydraulic Lock Capability

Custom Mounting Configuration

Swivel Foot and Jacking Pad

Counterbalance Valves

Porting options (ORB, NPT, C61) and Location

Standard and Split locking nut

Custom Paint To Your Spec

Pre-Engineered Leveling Cylinders Made in Canada

RHK Hydraulic Cylinders knows the importance of stabilizing your gear to ensure the safety of your crew and the efficiency of your project. At RHK our leveling cylinders are designed and manufactured in Alberta. Our pre-engineered lineup of Leveling Cylinders are manufactured to endure the harshest climate and working conditions. Standard features include:

High tensile, precision honed barrel

Chrome plated rod for long life and durability

65-45-12 Ductile Iron threaded gland

4 TPI ACME Theaded Barrel for locking capability

NPT Ports (1/8″, 3/8″, 1/4″)

Standard / Split locknut option

Leveling Cylinder Worksheet

Use this sheet to help design a custom cylinder and obtain a quote. Not all specs are required but the more information you can provide, the better.

Get A Quote

Leveling/Stabilizing Cylinders FAQ

What is a leveling cylinder?

Hydraulic leveling cylinders are used to stabilize a working platform. Also known as outriggers, stabilizers, leveling jacks and landing gear, they provide a stable base by distributing the load over a wider base. In short, it’s a device that helps keep your machinery level, stable, and safe. Leveling cylinders come in various sizes and capacities, so it’s important to choose one that’s appropriate for your needs.

What are the advantages to mechanical vs hydraulic locking leveling cylinders?

A mechanical locking leveling cylinder can achieve a compressive load strength 3-5 times the lifting capacity with zero deflection. A hydraulic locking leveling cylinder provides ease of use and reduced setup and tear down time.

What is the difference between a leveling cylinder regular nut and split nut?

Both styles of nut offer the ability to mechanically lock a cylinder at a specific extension. A standard nut is a solid, single piece machined from high tensile strength material. A split nut is very similar but split down the centre and hinged allowing for faster setup and tear down.
